10.1 Inch 1920*1080 LCD Monitor Screen AV101FHT-T10-28P0

  • 1
  • 2

Brand Name : BOE

Model Number : AV101FHT-T10-28P0

Place of Origin : China

MOQ : 1 pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000 Unit/Units per Month

Delivery Time : 7 Days

Packaging Details : Original packaging/conventional packaging box

Model Name : AV101FHT-T10-28P0

Screen Size : 10.1"

Pixel Number : 1920(RGB)×1080, FHD 218PPI

Active Area : 223.488(W)×125.712(H) mm

Pixel Format : RGB Vertical Stripe

Light Source : WLED [10S3P] , 30K hours , W/O Driver

Outline Dim. : 244.85(H)×159.25(V) mm

Treatment : Antiglare (Haze 10%), Hard coating (3H), Reflection

Luminance : 700 cd/m² (Typ.)

Designed For : Outdoor High Brightness ，Automotive Display

Contact Now

10.1 Inch 1920*1080 LCD Monitor Screen AV101FHT-T10-28P0


Product details :
Hello, before placing orders:

To avoid the wrong order or buy wrong product, please double check your model and screen size and part number. If you are not sure the purpose compatibility, please send your original specific models (screen) model on the back of the screen and photos sent to us; Usually we will send the LED panel is compatible model, it may be related to your original screen model is not completely the same. But we can make sure it is suitable for the model
Note: product prototype number of links and compatible model random delivery. If you have any special requirements you need to specify the type, please inform us before order. Thank you very much.

BrandBOE
Model P/NAV101FHT-T10-28P0
Diagonal Size10.1"
Panel Typea-Si TFT-LCD, Assembly
Resolution1920(RGB)×1080, FHD 218PPI
Pixel FormatRGB Vertical Stripe
Active Area223.488(W)×125.712(H) mm
Bezel Opening-
Outline Dim.244.85(H)×159.25(V) mm
TreatmentAntiglare (Haze 10%), Hard coating (3H), Reflection
Luminance700 cd/m² (Typ.)
Contrast Ratio1000:1 (Typ.) (TM)
View DirectionSymmetry
Response Time30 (Typ.)(Tr+Td)
Viewing Angle85/85/85/85 (Typ.)(CR≥10)
Operating ModeADS, Normally Black, Transmissive
Support Color16.7M 70% NTSC
Light SourceWLED [10S3P] , 30K hours , W/O Driver
Weight380±38g
Designed ForOutdoor High Brightness ,Automotive Display
Frame Rate60Hz
Touch PanelPCAP, I²C
Interface TypeLVDS (2 ch, 8-bit) , 60 pins Connector
Power Supply3.3V (Typ.)
EnvironmentOperating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C
