Brand Name : OPTREX
Model Number : T-51963GD035J-MLW-AGN
Place of Origin : China
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 100000 Unit/Units per Month
Delivery Time : 7 Days
Packaging Details : Original packaging/conventional packaging box
Model Name : T-51963GD035J-MLW-AGN
Diagonal Size : 3.5"
Panel Type : a-Si TFT-LCD, LCM
Resolution : 240(RGB)×320, QVGA 113PPI
Pixel Format : RGB Vertical Stripe
Active Area : 53.64(W)×71.52(H) mm
Designed For : Handheld & PDA
Frequency : 60Hz
NEW 3.5 inch T-51963GD035J-MLW-AGN 240*320 LCD Touch display
T-51963GD035J-MLW-AGN LCD Panel Product details :
Brand | OPTREX |
Model P/N | T-51963GD035J-MLW-AGN |
Diagonal Size | 3.5" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 240(RGB)×320, QVGA 113PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 53.64(W)×71.52(H) mm |
Bezel Opening | - |
Outline Size | 65(W)×86.2(H)×4.3(D) mm |
Brightness | 130 cd/m² (Typ.) |
Viewing Angle | 40/40/40/40 (Typ.)(CR≥10) |
Best View on | - |
Display Colors | 262K |
Frequency | 60Hz |
Weight | 50.0g (Max.) |
Surface | - |
Contrast Ratio | 70:1 (Typ.) (TM) 5:1 (Typ.) (RF) |
Display Mode | TN, Normally White, Transflective |
Response Time | 30/50 (Typ.)(Tr/Td) |
Lamp Type | WLED , 5K hours , Without Driver |
Touch Screen | 4-wire Resistive Touch |
Application | Handheld & PDA |
Signal Interface | CMOS (1 ch, 6-bit), 50 pinsFPC |
Input Voltage | 3.3/5.0/16.0/-12.0V (Typ.)(VDDD/VDDA/VGH/VGL) |
Environment | Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 70 °C |
NEW 3.5 inch T-51963GD035J-MLW-AGN 240*320 LCD Touch display |
T-51963GD035J-MLW-AGN LCD Panel Shipping and Package :
T-51963GD035J-MLW-AGN LCD Panel FAQ :
Q: Why big order delivery time are long?
A: All the lcd panel are Strictly tested before shipment , to ensure that you receive good quality lcd panel and work well!
Q: Are you manufactory or trade company?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can you declared low value for my order when shipping?
A: Yes, We can do it for you if you need.
Q: How to do if I can't find the screen that I require in your listings?
A: We should have it in stock , please contact us directly.if we dont't have it , we can try our best to find it for you .
![]() |
NEW 3.5 inch T-51963GD035J-MLW-AGN 240*320 LCD Touch display Images |
