Brand Name : OPTREX
Model Number : T-55343GD035JU-LW-AEN
Place of Origin : China
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 100000 Unit/Units per Month
Delivery Time : 7 Days
Packaging Details : Original packaging/conventional packaging box
Model Name : T-55343GD035JU-LW-AEN
Diagonal Size : 3.5"
Panel Type : a-Si TFT-LCD, LCM
Resolution : 320(RGB)×240, QVGA 115PPI
Pixel Format : RGB Vertical Stripe
Active Area : 70.08(W)×52.56(H) mm
Designed For : Handheld & PDA
Touch Screen : 4-wire Resistive Touch
Original 3.5 inch T-55343GD035JU-LW-AEN 320*240 LCD Touch Screen
T-55343GD035JU-LW-AEN LCD Panel Product details :
Brand | OPTREX |
Model P/N | T-55343GD035JU-LW-AEN |
Diagonal Size | 3.5" |
Panel Type | a-Si TFT-LCD, LCM |
Resolution | 320(RGB)×240, QVGA 115PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 70.08(W)×52.56(H) mm |
Bezel Opening | 72.8(W)×54.5(H) mm |
Outline(mm) | 79 × 65× 4.8 (H×V×D) |
Treatment | Antiglare |
Luminance | 320 cd/m² (Typ.) |
Contrast Ratio | 700 : 1 (Typ.) (TM) |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥5) |
Response | 8/15 (Typ.)(Tr/Td) ms |
Good View at | 12 o'clock |
Work Mode | TN, Normally White, Transmissive |
Color Depth | 16.7M 45%NTSC |
Backlight | 6S1PWLED, No Driver |
Mass | 46.5g (Max.) |
Used for | Handheld & PDA |
Refresh Rate | - |
Touchscreen | 4-wire Resistive Touch |
Signal Type | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins FPC |
Voltage Supply | 3.3V (Typ.)(VCC) |
Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
Original 3.5 inch T-55343GD035JU-LW-AEN 320*240 LCD Touch Screen |
T-55343GD035JU-LW-AEN LCD Panel Shipping and Package :
T-55343GD035JU-LW-AEN LCD Panel FAQ :
Q: How can I trace my order of T-55343GD035JU-LW-AEN ?
A: we will give you tracking number then you can trace your order from website.
Q: If I place order now,when will you ship the goods of T-55343GD035JU-LW-AEN ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Do you accept sample orders of T-55343GD035JU-LW-AEN ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of T-55343GD035JU-LW-AEN ?
A: Of course!If you make a large order, we will give you a discount.
![]() |
Original 3.5 inch T-55343GD035JU-LW-AEN 320*240 LCD Touch Screen Images |
