in stock 1880*120 23.0 inch PC230KT01-1 LCD screen lcd Panel

Brand Name : HKC

Model Number : PC230KT01-1

Place of Origin : China

MOQ : 1 pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000 Unit/Units per Month

Delivery Time : 7 Days

Packaging Details : Original packaging/conventional packaging box

Model Name : PC230KT01-1

Diagonal Size : 23.0" (Native bar)

Panel Type : a-Si TFT-LCD, CELL, FOB

Resolution : 1880×120(RGB) 82PPI

Pixel Format : RGB Horizontal Stripe

Active Area : 579.51(W)×36.99(H) mm

Used for : Digital Signage、Stretched Bar LCD

Touch Screen : Without

Contact Now

in stock 1880*120 23.0 inch PC230KT01-1 LCD screen lcd Panel

PC230KT01-1 LCD Panel Product details :

Brand	HKC
Model P/N	PC230KT01-1
Diagonal Size	23.0" (Native bar)
Panel Type	a-Si TFT-LCD, CELL, FOB
Resolution	1880×120(RGB) 82PPI
Pixel Format	RGB Horizontal Stripe
Active Area	579.51(W)×36.99(H) mm
Bezel Opening	-
Outline Dim.	590.91(H)×43.99(V)×1.33(D) mm
Treatment	Antiglare (Haze 3%), Hard coating (3H)
Luminance	0 cd/m²
Contrast Ratio	3000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	5 (Typ.)(G to G)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Operating Mode	FSA, Normally Black
Plate Thickness	0.50+0.50 mm
Transmittance	5.0% (Typ.)(with Polarizer)
Support Color	16.7M 68%NTSC
Light Source	No B/L
Weight	TBD
Designed For	Digital Signage,Stretched Bar LCD
Frame Rate	60Hz
Touch Panel	Without
D-IC Detail	COF Built-in 1 chips
Interface Type	LVDS (2 ch, 8-bit), 51 pinsConnector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
in stock 1880*120 23.0 inch PC230KT01-1 LCD screen lcd Panel

PC230KT01-1 LCD Display Features :

High Quality:

Highest quality touch LCD screen replacement parts.

Repair Utility:

Suitable for repairing faulty screens, touch screen problems, dead pixels, cracked touchscreens, and other related issues.

Thorough Testing:

Each assembly is tested before shipping to ensure 100% functionality.

Quality control includes checks for dark spots, color points, and dead pixels, ensuring no defects.

PC230KT01-1 LCD Panel Shipping and Package :

in stock 1880*120 23.0 inch PC230KT01-1 LCD screen lcd Panel

PC230KT01-1 LCD Display Shipping Policy :

Shipping Method:

If the buyer selects a specific courier (e.g., FedEx), we may ship the product using an equivalent service level from other logistics companies such as DHL, UPS, TNT, or others.

Specified Logistics:

If you require a specific logistics company, please inform us in advance.

PC230KT01-1 LCD Display Return Policy :

Product Status:

The product's condition (new or old) will be indicated in the product title.

Return and Exchange Conditions:

If the product encounters quality problems within 30 days of receipt, we offer free returns and exchanges.

Return Procedure:

When returning the product, please provide a detailed explanation of the issues encountered.

Include actual photos showing the problems with the product.

PC230KT01-1 LCD Panel FAQ :

Q: Do you accept sample orders of PC230KT01-1 ?

A: Of course!sample order is welcome !

Q: How can I trace my order of PC230KT01-1 ?

A: we will give you tracking number then you can trace your order from website.

Q: If I place order now,when will you ship the goods of PC230KT01-1 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity of PC230KT01-1 ?

A: Of course!If you make a large order, we will give you a discount.
