Brand Name : JDI
Model Number : LPP060A517F-01
Place of Origin : China
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 100000 Unit/Units per Month
Delivery Time : 7 Days
Packaging Details : Original packaging/conventional packaging box
Model Name : LPP060A517F-01
Diagonal Size : 6.0"
Panel Type : a-Si TFT-LCD, CELL, Full Cell
Resolution : 1080(RGB)×2160 403PPI
Pixel Format : RGB Vertical Stripe
Active Area : 68.04(W)×136.08(H) mm
Designed For : Mobile Phone
Touch Screen : In-Cell Touch
Operating Mode : IPS, Normally Black, Transmissive
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10)
NEW 6.0 inch LPP060A517F-01 1080*2160 LCD Display Screen
LPP060A517F-01 LCD Panel Product details :
Brand | JDI |
Model P/N | LPP060A517F-01 |
Diagonal Size | 6.0" |
Panel Type | a-Si TFT-LCD, CELL, Full Cell |
Resolution | 1080(RGB)×2160 403PPI |
Pixel Format | RGB Vertical Stripe |
Active Area | 68.04(W)×136.08(H) mm |
Bezel Opening | - |
Outline Dim. | 69.24(W)×140.98(H)×0.3(D) mm |
Treatment | Without Polarizer |
Luminance | 0 cd/m² |
Contrast Ratio | 1500:1 (Typ.) (TM) |
View Direction | Symmetry |
Response Time | 30 (Typ.)(Tr+Tf) |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
Operating Mode | IPS, Normally Black, Transmissive |
Plate Thickness | 0.15+0.15 mm |
Transmittance | 4.3% (Typ.) |
Support Color | 16.7M 83%NTSC |
Light Source | No B/L |
Weight | 7.00g (Typ.) |
Designed For | Mobile Phone |
Frame Rate | 60Hz |
Touch Panel | In-Cell Touch |
D-IC Detail | COG Suggest NT36672, TD4310 |
Interface Type | MIPI (4 data lanes) |
Power Supply | 1.8/5.5/-5.5V (Typ.)(IOICC/VSP/VSN) |
Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
LPP060A517F-01 LCD Panel Shipping and Package :
LPP060A517F-01 LCD Panel FAQ :
Q: How do you ship my goods LPP060A517F-01 ?
A: We can shipping all over the world.via DHL,UPS,Fedex and EMS, the packaging is very safe and strong.
Q: How long is the warranty of LPP060A517F-01 ?
A: 90days warranty .
Q: Are you manufactory or trade company ?
A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
Q: Can You declare my order of LCD panel LPP060A517F-01 at a very low value ?
A: Yes , we can . pls inform us before shipping .
![]() |
NEW 6.0 inch LPP060A517F-01 1080*2160 LCD Display Screen Images |
