Brand Name : TIANMA
Model Number : TA064VGWX02
Place of Origin : China
MOQ : 1 pcs
Price : Negotiable
Payment Terms : T/T, Western Union
Supply Ability : 100000 Unit/Units per Month
Delivery Time : 7 Days
Packaging Details : Original packaging/conventional packaging box
Model Name : TA064VGWX02
Diagonal Size : 6.3"
Panel Type : AM-OLED, OLED, FOB
Resolution : 1080×2340
Pixel Format : Sub-Pixel Rendering
Display Mode : 68.04(W)×147.42(H) mm
Best View on : Symmetry
Environment : Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C
Lamp Type : self
Used for : Mobile Phone
TA064VGWX02 6.3 inch 1080*2340 LCD Panel Display
TA064VGWX02 LCD Panel Product details :
Brand | TIANMA |
Model P/N | TA064VGWX02 |
Diagonal Size | 6.3" |
Panel Type | AM-OLED, OLED, FOB |
Resolution | 1080×2340 |
Pixel Format | Sub-Pixel Rendering |
Active Area | 68.04(W)×147.42(H) mm |
Bezel Opening | - |
Outline Dim. | 69.94(H)×150.47(V) mm |
Treatment | Hard coating |
Luminance | 350 cd/m² (Typ.) |
Contrast Ratio | 10000:1 (Min.) (TM) |
View Direction | Symmetry |
Response Time | 16 (Max.)(Tr+Td) |
Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
Operating Mode | - |
Support Color | 16.7M 100%NTSC |
Light Source | self |
Weight | - |
Designed For | Mobile Phone |
Frame Rate | - |
Touch Panel | On-Cell Touch |
D-IC Detail | COF Built-in NT37700F |
Environment | Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C |
TA064VGWX02 LCD Panel Shipping and Package :
TA064VGWX02 LCD Panel FAQ :
Q: How can I trace my order of TA064VGWX02 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can you give me a discount if I need a large quantity of TA064VGWX02 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of TA064VGWX02 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
![]() |
TA064VGWX02 6.3 inch 1080*2340 LCD Panel Display Images |
